Figurine - a vector graphics editor
Figurine is an X11 program for editing vector graphic figures and diagrams. It uses the xfig
FIG3.2 format, and uses the transfig package for output. It should be portable
to any UNIX-like X11R4 or better system.
Figurine is intended to be considerably easier to use than xfig, but providing a similar set of
features. The manual includes configuration and installation instructions.
You can download Figurine from the sourceforge page http://sourceforge.net/projects/figurine/. Figurine is released under the GNU GPL.
You will need to get the transfig 3.2 package, available at http://www.xfig.org. Figurine also supports the external transfig patch for MetaPost at http://www-sp.iti.informatik.tu-darmstadt.de/software/xfig/.
The sourceforge page also has a bug tracker, allowing you to report bugs and browse the list of known bugs.
Figurine was written in a whirlwind of bad coding practices and badly planned design by John Levon, moz@compsoc.man.ac.uk.
